| 범주: | 여행 드라이브 부품 | 부품 번호: | 1010474 |
|---|---|---|---|
| 제품 이름: | 담체 | 기계 번호: | EX300 EX300-2 |
| 애플리케이션: | 굴착기 | 리드 타임: | 배송 1-3 일 |
| 포장: | 표준 내보내기 상자 | ||
| 강조하다: | Hitachi excavator spare parts EX300,Carrier excavator fittings EX300-2,Excavator replacement parts with warranty |
||
1010474 Carrier HITACHI Excavator Spare Parts Fitting For EX300 EX300-2
Specifiion
| Category | Travel Drive Parts |
| Name | Carrier |
| Parts No | 1010474 |
| Machine Number | EX300 EX300-2 |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT |
| Packing | As request or standard packing |
1.Planetary Gear Mounting: Secures planetary gears in precise alignment, ensuring efficient torque transfer between the sun gear and output flange. Misalignment (from a damaged Carrier) causes gear tooth chipping and uneven wear.
2.Torque Transmission: Acts as the "middleman" in the swing drive’s power flow, converting the planetary gears’ orbital motion into rotational torque for the upper structure.
3.Load Bearing: Supports the combined weight of the upper structure and dynamic loads from swing operations (e.g., digging while rotating), preventing the swing drive from collapsing or shifting.
4.Component Protection: Shields internal gears and bearings from external debris (e.g., dirt, rocks) and guides lubricating oil to critical contact points, extending the swing drive’s service life.
EXCAVATORS EX300 EX300-2 Hitachi
| 1014809 CARRIER |
| 270C LC JD, CX700HD, CX900, CX900-2, CX900HD, EX270-5, EX280H-5, EX300-2, EX300-3, EX300-3C, EX310H-3C, SCX700HD, SCX900, SCX900HD, SCX900HD-C, ZX270, ZX270-HHE, ZX280LC-AMS, ZX280LC-HCME, ZX300W |
| 1010468 CARRIER |
| EX270, EX300, EX300-2 |
| 1014808 CARRIER |
| 270C LC JD, CX700HD, CX900, CX900-2, CX900HD, EX270-5, EX280H-5, EX300-2, EX300-3, EX300-3C, EX310H-3C, SCX700HD, SCX900, SCX900HD, SCX900HD-C, ZX270, ZX270-HHE, ZX280LC-AMS, ZX280LC-HCME, ZX300W |
| 1010475 CARRIER |
| EX300, EX300-2 |
| 2023371 CARRIER |
| EX270, EX300 |
| 2024993 CARRIER |
| EX270, EX300 |
| 2033936 CARRIER |
| EX270, EX300 |
| 0952102 CARRIER (1) |
| SCX700-2, SCX800-2, SCX800HD-2 |
| 563G0-60121 CARRIER |
| ZW220, ZW220-DO |
| 56190-71811 CARRIER ASSY |
| LX70-7, ZW100, ZW100-DO, ZW100-G |
| 2031036 CARRIER |
| EX60-2, EX60-3, EX60LCK-3, EX60LCT-3, EX60T-2, EX60WD-2, EX75UR, EX75UR-3, EX75URLC-3 |
| 2016633 CARRIER |
| UH103 |
| 1035047 CARRIER |
| ZX670LC-5B, ZX670LC-5G, ZX670LCH-5B, ZX670LCH-5G, ZX670LCR-5G |
| 1027160 CARRIER |
| ZX200, ZX225US, ZX225US-E, ZX225US-HCME, ZX225USR, ZX225USR-E, ZX225USRK, ZX230, ZX230-HHE, ZX240H, ZX240K, ZX240LC-HHE, ZX250-HCME, ZX450 |
| 1019147 CARRIER |
| CHR70, EX200-3, EX200-3C, EX200-3E, EX200-5, EX200-5 JPN, EX200-5HG, EX200-5HHE, EX200-5LV JAP, EX200-5X JPN, EX200-5Z JPN, EX200K-3, EX200LC-5HHE, EX200SS-5, EX210H-5, EX210H-5 JPN, EX210K-5 JPN, EX2... |
| 1026081 CARRIER |
| EX135UR-5, EX135US-5, EX135USR, EX135USRK, EX140US-5 |
| 1008731 CARRIER |
| UH103, UH123 |
| 0887201 CARRIER |
| UCX300, ZX210W, ZX210W-AMS, ZX300W |
| Pos. | Part No | Qty | Parts name | Comments |
| 0 | 9069422 | [1] | MOTOR;OIL | Y 9082057 |
| 0 | 9082057 | [1] | MOTOR;OIL | |
| 00-52. | 9069550 | [2] | TRAVEL DEVICE ASS'Y | Y 9096486 |
| 00-59. | 9096486 | [2] | TRAVEL DEVICE ASS'Y | |
| 00A. | 9071903 | [1] | VALVE;BRAKE | Y 9082178 |
| 00A. | 9082178 | [1] | VALVE;BRAKE | |
| 2 | 1010465 | [1] | HOUSING | |
| 3 | 4066695 | [1] | SEAL;GROUP | |
| 4 | 4192975 | [2] | BRG.;ROL. | |
| 5 | 1010466 | [1] | DRUM | |
| 6 | 1010467 | [1] | SPROCKET | |
| 7 | A590920 | [16] | WASHER;SPRING | |
| 8 | J932060 | [16] | BOLT | |
| 10 | 3036256 | [1] | NUT | |
| 11 | 4192974 | [1] | PLATE;LOCK | |
| 12 | J901225 | [2] | BOLT | |
| 14 | 1010468 | [1] | CARRIER | |
| 15 | 3036257 | [3] | GEAR;PLANETARY | |
| 16 | 4192976 | [6] | BRG.;NEEDLE | |
| 17 | 4201913 | [6] | PLATE;THRUST | Y 4219595 |
| 17 | 4219595 | [6] | PLATE;THRUST | |
| 18 | 4192978 | [3] | PIN | |
| 19 | 4192021 | [3] | PIN;SPRING | |
| 20 | 3036258 | [1] | GEAR;SUN | |
| 23 | 1010473 | [1] | GEAR;RING | |
| 24 | A590916 | [26] | WASHER;SPRING | |
| 25 | J931645 | [24] | BOLT | |
| 27 | 1010475 | [1] | CARRIER | |
| 28 | 4192979 | [2] | SPACER | |
| 29 | 3036264 | [3] | GEAR;PLANETARY | |
| 30 | 4190117 | [3] | BRG.;NEEDLE | |
| 31 | 4192982 | [6] | PLATE;THRUST | |
| 32 | 4144558 | [3] | PIN | |
| 33 | 4144525 | [3] | PIN;SPRING | |
| 34 | 3036266 | [1] | GEAR;SUN | |
| 35 | 1010474 | [1] | CARRIER | |
| 37 | 3036265 | [3] | GEAR;PLANETARY | |
| 38 | 4108021 | [3] | BRG.;NEEDLE | |
| 39 | 4192983 | [6] | PLATE;THRUST | |
| 40 | 4192977 | [3] | PIN | |
| 41 | 4192020 | [3] | PIN;SPRING | |
| 42 | 2023188 | [1] | SHAFT;PROP. | |
| 43 | 4204756 | [1] | CAP | |
| 44 | 2024646 | [1] | COVER | P 2028461 |
| 44 | 2028461 | [1] | COVER | P 2031912 |
| 44 | 2028461 | [1] | COVER | P 4278011 |
| 44 | 2028461 | [1] | COVER | P 4278168 |
| 44 | 2028461 | [1] | COVER | P 930451 |
| 44 | 2031912 | [1] | COVER | |
| 44 | 2031913 | [1] | COVER | |
| 45 | A590912 | [12] | WASHER;SPRING | |
| 47 | 4245797 | [3] | PLUG | |
| 47 | 94-2013 | [2] | PLUG | |
| 47 | 94-2013 | [3] | PLUG | Y 4245797 |
| 49 | J931685 | [2] | BOLT | |
| 50 | 4193063 | [1] | O-RING | |
| 52 | J011230 | [12] | BOLT;SEMS | |
| 52 | M221228 | [12] | BOLT | I J011230 |
| 54 | M492564 | [2] | SCREW;DRIVE | |
| 55 | 3053559 | [1] | NAME-PLATE | |
| 57 | 4277474 | [1] | PIN;STOPPER | |
| 57 | 4278011 | [1] | PIN;STOPPER | |
| 58 | 4278168 | [1] | BRG.;BALL | |
| 59 | 930451 | [1] | RING;RETAINING | |
| 60 | J932080 | [34] | BOLT | |
| 61 | A590920 | [34] | WASHER;SPRING |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
