제품 상세 정보:
결제 및 배송 조건:
|
| 범주: | 작업장비 조절레버 | 기계 모델: | WA200 WA250 WA320 WA380 WA400 |
|---|---|---|---|
| 제품명: | 손잡이 | 응용: | 휠 로더 |
| 부품 번호: | 22U-06-22470 22U-06-22380 | 포장: | 표준 수출 상자 |
| 강조하다: | Komatsu wheel loader knob,WA200 WA250 WA320 spare parts,excavator replacement knob |
||
| Appliion | Wheel Loaders |
| Name | Knob |
| Parts No | 22U-06-22470 22U-06-22380 |
| Machine Model | WA200 WA250 WA320 WA380 WA380Z WA400 |
| Category | Loader Control Unit, Work Equipment Control Lever |
| Lead time | 1-3 DAYS |
| Quality | Brand new, OEM quality |
| MOQ | 1 PCS |
| Means of transport | By sea/air, DHL FEDEX UPS TNT EMS |
| Packing | As request or standard packing |
| 1.This knob is typically installed on control levers, joysticks, or adjustment handles in the operator’s cab. |
| 2.It serves as the hand‑operated grip for controlling machine functions such as: |
| Travel / movement |
| Boom, arm, and bucket operation |
| Auxiliary hydraulic functions |
| Mode selection or adjustment |
WHEEL LOADERS WA200 WA200PT WA200PZ WA250 WA250PT WA250PZ WA320 WA320L WA320PT WA320PZ WA380 WA380Z WA400 WA430 WA450 WA470 WA480 WA500 WA800 Komatsu
| 22B-54-15470 KNOB,L.H. |
| PC220, PC240, PC290, PC300, PC350, PRESSURE, RAIN |
| 21T-43-31190 KNOB |
| PC2000, TRAVEL |
| 22B-43-11230 KNOB ASS'Y,R.H. |
| PC128US, PC128UU, PC158, PC158US |
| 421-57-31650 KNOB ASS'Y |
| AIR, FRONT, HD325, HD405, HD465, HD605, HD785, HM250, HM300, HM350, HM400, HYDRAULIC, WA150, WA200, WA380, WA400, WA430, WA470, WA480, WA500 |
| 42A-56-53590 Knob |
| WA50 |
| TW7034-0180 KNOB |
| PC128US, PC128UU, PC158, PC158US, PC228, PC228US, PC228UU, PC78US |
| 20Y-43-41780 Knob |
| D39EX, D39PX, PC130, PC220, PC240, PC290, PC300, PC350, PRESSURE, RAIN |
| 20U-43-41280 KNOB,SWITCH |
| PC58UU, PC78UU |
| 41F-43-18200 KNOB |
| WD500, WD600, WD900 |
| 23E-57-11150 KNOB |
| GD305A, GD355A, GD405A, GD505A, GD605A, GD621R, GD705A, GD825A, GH320 |
| 195-43-64211 KNOB ASS'Y |
| D275A, D275AX, D375A, D475A |
| 234-870-0150 KNOB ASS'Y,FRONT BLADE |
| GD300A, GD500R, GD505A, GD600R, GD605A, GD655A, GD705A, GD705R |
| Pos. | Part No | Qty | Parts name | Comments |
| 1 | 01010-81025 | [4] | Bolt Komatsu | 0.36 kg. |
| ["SN: 70001-UP"] analogs:["0101051025", "0101651025", "801015109"] | ||||
| 2 | 01643-31032 | [4] | Washer Komatsu | 0.054 kg. |
| ["SN: 70001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 2 | 418-43-48241 | [1] | Lever Assembly Komatsu China | |
| ["SN: 70987-UP"] | ||||
| 2 | 418-43-48240 | [1] | Lever Assembly Komatsu China | |
| ["SN: 70001-70986", "SCC: A2"] | ||||
| 4. | 23S-43-31550 | [1] | Nut Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 5. | 23S-43-51230 | [1] | Grommet Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 6. | 287-43-18350 | [1] | Grommet Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 7. | 421-43-37591 | [1] | Lever Komatsu | 0.15 kg. |
| ["SN: 70001-UP"] | ||||
| 8. | 421-43-38430 | [1] | Collar Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9. | 418-43-48261 | [1] | Knob Assembly Komatsu China | |
| ["SN: 70987-UP"] | ||||
| 9. | 418-43-48260 | [1] | Knob Assembly Komatsu China | |
| ["SN: 70001-70986", "SCC: A2"] | ||||
| 9 | 421-43-38513 | [1] | Body Assembly Komatsu China | |
| ["SN: 70987-UP"] | ||||
| 9 | 421-43-38512 | [1] | Body Assembly Komatsu | 0.04 kg. |
| ["SN: 70001-70986", "SCC: A2"] | ||||
| 9 | 423-43-48290 | [1] | Switch Assembly Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38523 | [1] | Cap Komatsu China | |
| ["SN: 70987-UP"] | ||||
| 9 | 421-43-38522 | [1] | Cap Komatsu | 0.02 kg. |
| ["SN: 70001-70986", "SCC: A2"] | ||||
| 9 | 421-43-38530 | [1] | Spacer Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38540 | [1] | Spring Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38550 | [1] | Cap Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38560 | [1] | Ring Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38570 | [1] | Plunger Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38580 | [1] | O-ring Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 421-43-38740 | [1] | Stopper Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 9 | 418-43-48230 | [1] | Lever Assembly Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 12. | 421-43-38332 | [1] | Knob Komatsu | 0.2 kg. |
| ["SN: 70001-UP"] | ||||
| 14 | 23S-43-51111 | [2] | Lever Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 15 | 01583-11408 | [2] | Nut Komatsu | 0.4 kg. |
| ["SN: 70001-UP"] analogs:["801713411"] | ||||
| 16 | 01546-10812 | [2] | Nut Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 17 | 01643-50823 | [2] | Washer Komatsu | 0.01 kg. |
| ["SN: 70001-UP"] analogs:["0164370823"] | ||||
| 18 | 418-43-48140 | [1] | Lever Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 19 | 09305-00800 | [1] | Knob, Red Komatsu | 0.05 kg. |
| ["SN: 70001-UP"] | ||||
| 20 | 20S-26-71250 | [2] | Pin, Spring Komatsu China | |
| ["SN: 71926-UP"] analogs:["890001458"] | ||||
| 20 | 04025-00520 | [2] | Pin, Spring Komatsu | 0.002 kg. |
| ["SN: 70001-71925"] | ||||
| 21 | 418-43-38131 | [1] | Shaft Komatsu | 1 kg. |
| ["SN: 70001-UP"] | ||||
| 22 | 421-09-21220 | [4] | Bushing Komatsu | 0.001 kg. |
| ["SN: 70001-UP"] | ||||
| 23 | 203-43-21370 | [1] | Spring Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 24 | 418-43-38120 | [1] | Lever Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 25 | 04256-40616 | [1] | Joint, Ball Komatsu | 0.067 kg. |
| ["SN: 70001-UP"] | ||||
| 26 | 418-43-28150 | [1] | Rod Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 27 | 01580-10605 | [1] | Nut Komatsu | 0.01 kg. |
| ["SN: 70001-UP"] analogs:["21D0921430", "M018200600006", "801920103"] | ||||
| 28 | 01508-40603 | [1] | Nut, Left-handed Komatsu | 0.01 kg. |
| ["SN: 70001-UP"] analogs:["0150820603"] | ||||
| 29 | 04256-50616 | [1] | Joint, Ball Komatsu | 0.037 kg. |
| ["SN: 70001-UP"] | ||||
| 30 | 418-43-38112 | [1] | Bracket Komatsu China | |
| ["SN: 70001-UP"] | ||||
| 31 | 01010-81220 | [2] | Bolt Komatsu | 0.032 kg. |
| ["SN: 70001-UP"] analogs:["0101051220"] | ||||
| 32 | 01643-31232 | [2] | Washer Komatsu | 0.027 kg. |
| ["SN: 70001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 33 | 20Y-62-15651 | [1] | Valve Komatsu | 0.474 kg. |
| ["SN: 70001-UP"] | ||||
| 34 | 07283-33442 | [2] | Clip, Pipe Komatsu | 0.094 kg. |
| ["SN: 70001-UP"] | ||||
| 36 | 01597-01009 | [4] | Nut Komatsu | 0.011 kg. |
| ["SN: 70001-UP"] | ||||
| 37 | 426-09-11130 | [2] | Nut Komatsu | 0.002 kg. |
| ["SN: 70001-UP"] analogs:["0159600606"] |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Advantage
1. Offer Top quality & competitive products
2. Support 12-month warranty
3. 100% tested before shipping
4. Delivery in time
5. A wide range of Oil Pressure Sensor, Fuel Tank Level Sensor, Temperature Sensor, Speed Sensor for excavator
6. More than 15 years production and 11 years foreign trade experience
7. Professional QC team
8. Best sales team, 24 hours service
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
